SENMATIC热电偶PTR系列技术参数
Threaded immersion thermometer without extension length and with fixed insert for measurement of temperatures in gases, vapours, and fluids, e.g. in sealed pipelines and containers - in the LOW PRESSURE RANGE. |
Fixed measuring insert according to IEC 751, standard 1/3 DIN. |
Protective sheath of Ø8x1 mm of stainless steel AISI316. |
1/2” BSP mounting thread. (Rated torque: max. 50 Nm.) |
Form B connection head of light-alloy metal according to DIN 43729, protection IP 65, cable gland M20. |
Response time (mean values) measured at velocities in: water at 0.4 m/s: t0.5 = 7 sec. - t0.9 = 27 sec. ; air at 3.0 m/s: t0.5 = 40 sec. |
Recommended measuring current: max. 2 mA. |
Approvals: DNV-GL, DNV-GL EU RO MR. |
SENMATIC热电偶PTR系列选型
SENMATIC热电偶其他常用型号：
SENMATIC 367626-0005
SENMATIC Type A
SENMATIC Type B
SENMATIC Type BF
SENMATIC Type BL
SENMATIC Type BN
SENMATIC Type CL
SENMATIC Type DMH
SENMATIC Type DW
SENMATIC Type HMI60
SENMATIC thermocouple NEW + ORIGINAL+ ONE YEAR WARRANTY
爱泽工业成立于2010年，定位于向制造工业提供高端制造技术和设备。代理经营世界优质的电气自动化、机械与传动、流体控制、仪器仪表、工具等产品。作为电气，液压以及气动解决方案的合作伙伴，我们利用我们的全球协作团队，为客户提供先进解决方案，市场知识以及相关增值服务来帮助优化客户的工作效率，提高可靠性和安全性，致力于成为工业产品和解决方案的优质渠道。
如果有任何关于SENMATIC热电偶367626-0005的疑问，请随时与我们沟通（021-31006702）。我们将尽全力解决您的问题。
If you have any question for SENMATIC products, please feel free to dial 0086-21-3100 6702/ send request email to [email protected] / browse our website:www.ize-industries.com.
SENMATIC热电偶PTR系列367626-0005技术参数及选型
