Compliance

RoHS Directive 2011/65/EU as last update by 2015/65/EU REACH Regulation (EC) n°1907/2006

Ambient temperature

Standard execution = -30°C ÷ +70°C
/PE option = -20°C ÷ +70°C
/BT option = -40°C ÷ +70°C

Seals, recommended fluid temperature

NBR seals (standard) = -20°C ÷ +80°C, with HFC hydraulic fluids = -20°C ÷ +50°C
FKM seals (/PE option) = -20°C ÷ +80°C
HNBR seals (/BT option) = -40°C ÷ +60°C, with HFC hydraulic fluids = -40°C ÷ +50°C

Recommended viscosity

15+100 mm²/s - max allowed range 2,8 + 500 mm²/s

Max fluid contamination level

ISO4406 class 20/18/15 NAS1638 class 9, see also filter section at www.atos.com or KTF catalog

Subplate surface finishing

Roughness index Ra 0,4 - flatness ratio 0,01/100 (ISO 1101)
